ARES-200D, 200 A DC Micro-ohm Meter with built-in Printer

Measurement Parameter
Contact Resistance

Measurement Modes
Static Resistance, Dynamic Resistance & Dual ground

Test Current
1 A to 200 A

Measurement Range
0.1 µΩ to 5 Ω

Accuracy
Typical: 0.1% ± 0.1% FsGuaranteed: 0.5% ± 0.1% Fs

Display
4.3-inch TFT touch Display (visible under sunlight)

Memory
Up to 200 records with 25 intervals for each

Communication
USB 2.0/1.1 Standard-A, USB 2.0/1.1 Standard-B, Bluetooth (factory-installed option)

PC Software
DMP Software

Printer
2.25-inch Built-in Printer

Test Plan
Up to 6 plans

Current Clamp
Yes, Optional

Power Supply
100-240 V 47/63 Hz

Dimensions
16.7″ x 13.4″ x 6.8″  (424 mm x 340 mm x 173 mm )

Weight
9 kg

Operating and Storage temperature
Working:   -10 °C to + 60 °CStorage:     -30 °C to 70 °C

Humidity
95% RH non-condensing

Protection Class
IP67 (case closed)

Set of Package
DARES-200, Power Cable, Ground Cable, 10 m (33 ft.) Standard Test Cable Set, USB Cable, Printer Paper (x2), USB flash drive, Instruction Manual (Soft Copy), DMP Software, Cable Bag

Options
Hard Carrying Case, Length Customised Cables, Bluetooth (factory-installed option), Current Clamp
